CANVAP PE02
CANLON
PRODUCT DESCRIPTION
CANVAPTM PE02 waterproof breathable film is made of high density polyethylene through special spunbond process, designed for air tightness and condensation control of various building structures. It has the functions of impermeability, waterproof and breathability. It can prevent indoor water vapor from penetrating into the envelope structure, so as to effectively ensure the thermal performance of insulation materials and durability of the structures.
USES
CANVAPTM PE02 may only be used by experienced professionals.
As a waterproof breathable barrier over most common wall types:
l Concrete / cementitious
l Metal Plywood panels, curtain wall, timber boards
CHARACTERISTICS / ADVANTAGES
l Excellent air tightness and water tightness — Membrane easily forms water-tight overlaps without special treatment, to reduce heat convection and improve building energy efficiency.
l Breathability — Helps water vapor spread to keep insulation layer dry.
l Stays flexible at low temperatures.
l Excellent durability.
l High strength — Multi-layer composite structure guarantees excellent strength of the film.
l Waterproof, moisture-proof and mildew proof — Membrane effectually slow down moisture diffusion to insulation layer, protecting thermal performance of wall structure and avoiding mildew.
PRODUCT INFORMATION
Chemical Base | High density polyethylene | |
Packaging | Roll size | |
Length | 30-100 m | |
Width | 1-3 m | |
Thickness | 0.2 mm | |
Refer to current price list for packaging variations | ||
Appearance / Colour | Surface: PE foil | |
Shelf Life | 12 months from production date. | |
Storage Conditions | Be stored in original unopened and undamaged sealed packaging in dry conditions and temperatures between +5 °C and +35 °C. Store in a horizontal position. Do not stack pallets of the rolls on top of each other, or under pallets of any other materials during transport or storage. | |
TECHNICAL INFORMATION
Tensile Strength | ≥ 300 N/50 mm |
Tear Strength | ≥ 40 N |
Water Vapour Transimission Rate | ≥ 1000 g/m2·24h |
Water Tightness | ≥ 1000 mm |
Flexibility at low Temperature | -30 °C |
Tensile Strength Retention Rate After Heat Aging | longitudinal ≥ 80% |
transversal ≥ 80% |
APPLICATION INSTRUCTIONS
l Before laying the film, a quality inspection should be conducted on previous process to ensure it is qualified before proceeding with the construction.
l Substrate: The supporting structure must be of sufficient structural strength to apply all new and existing layers. A uniform, clean, dry, firm, and smooth substrate must be required without any sharp protrusion, burrs, grease, bitumen, oil, dust and loose surface sand / gravel dressing. Dust must be completely removed before application of the product by suitable dust extraction equipment.
l Strictly follow installation procedures as defined in method statements, application manuals and working instructions which must always be adjusted to the actual site conditions.
l Measure and cut membrane according to construction drawings. Ensure that the size is accurate and the edge is neat.
l CANVAPTM PE02 is usually layed directly on structural deck, and fixed with insulation board through fastener, or directly pressed and integrated with the system. The film should be smooth and straight when laying on structural wall, no folds.
l Use smooth shank, electro-plated galvanized nails for fastening shingles to get the best seal. Hand nailing generally provides a better seal than power-activated nailing. If nailing of the membrane is necessary on steep slopes during hot or extreme cold weather, backnail and cover the nails by overlapping with the next sheet.
l All details such as internal and external corners, upstands, vent pipes, support metalwork etc. must be cut and sealed effectively. CANVAPTM PE02 must always be attached on the warm side of the thermal insulation. The upper edge of the CANVAPTM PE02 must be taken up to the top edge / surface of the insulation.
l The film should be constructed on the building facade in sections according to the height, from bottom to top. Each section should be paved from top to bottom, and the sections should be overlapped vertically in the direction of water flow.
l Pay special attention to the sealing treatment at the overlapping parts and perforations of the membrane. Ensure that it is dry before sealing.
l After the installation is completed, an engineering inspection should be carried out to ensure that the various properties of the film meet the design requirements.
LIMITATIONS
l Installation work must only be carried out by trained and approved contractors experienced in this type of application.
l Not suitable as permanent waterproofing. It is not designed as a wall membrane and therefore cannot replace the waterproofing membrane, only as a vapour barrier.
l Apply CANVAPTM PE02 in fair weather when the air, substrate, and film are at temperatures of -5°C to 50°C. If the temperature falls outside this range, insulation or cooling measures should be taken. Construction should be avoided under conditions of wind force 5 or above. In case of abnormal weather, protective measures should be taken and temporary fixation should be increased.
VALUE BASE
All technical data stated in this Data Sheet are based on laboratory tests. Actual measured data may vary due to circumstances beyond our control.
LOCAL RESTRICTIONS
Note that as a result of specific local regulations the declared data and recommended uses for this product may vary from country to country. Consult the local Product Data Sheet for the exact product data and uses.
ECOLOGY, HEALTH AND SAFETY
Fresh air ventilation must be ensured, when working (welding) in closed rooms.
LEGAL NOTES
The information, and, in particular, the recommendations relating to the application and end-use of Canlon products, are given in good faith based on Canlon's current knowledge and experience of the products when properly stored, handled and applied under normal conditions in accordance with Canlon's recommendations. In practice, the differences in materials, substrates and actual site conditions are such that no warranty in respect of merchantability or of fitness for a particular purpose, nor any liability arising out of any legal relationship whatsoever, can be inferred either from this information, or from any written recommendations, or from any other advice offered. The user of the product must test the product’s suitability for the intended application and purpose. Canlon reserves the right to change the properties of its products. The proprietary rights of third parties must be observed. All orders are accepted subject to our current terms of sale and delivery. Users must always refer to the most recent issue of the local Product Data Sheet for the product concerned, copies of which will be supplied on request.
